Meiosis, which is characterized by two rounds of chromosome segregation but only one round of DNA replication, is the foundation of propagation and inheritance in sexual reproduction. Errors in chromosome separation result in aneuploidy, associated with oocyte maturation failure and consequences for aneuploidy or dysplasia in the embryo [1]. A variety of protein kinases regulate chromosome alignment and separation through phosphorylation and dephosphorylation pathways to achieve high quality-matured oocytes, and the ability to support subsequent fertilization and embryo development [2].

The casein kinase 1 (CK1) is a family of serine/threonine protein kinases, commonly existing in all eukaryotes [3]. This abundant enzymes CK1, function as monomeric (34-55 k Da) and constitutively active enzymes [4]. Until now, seven family members of CK1 were identified, which are encoded by different genes, including alpha, beta 1, gamma 1, gamma 2, gamma 3, delta, and epsilon (α, β, γ1, γ2, γ3, δ, ε) [5]. All CK1 members are quite homologous (50% identical or greater) and highly conserved within their kinase domains, but differ significantly in the length and primary structure of their C-terminal and N-terminal non-catalytic domain which is an extended tail in the case of CK1δ/ε as opposed to CK1α which has a limited C-terminal domain, but CK1γ isoforms on the other hand vary in a longer N-terminal head [6]. Although CK1 isoforms and associated splice variants are ubiquitously expressed, their activity is greatly regulated via their expression levels [7], post-translational modifications by various mechanisms including subcellular stimuli [8], subcellular compartmentalization [9], proteolytic cleavage of the C-terminus, autoand de-phosphorylation of the C-terminal regulatory domain [10].

A large number of substrates have been identified that are phosphorylated by CK1 isoforms in vitro or in vivo. CK1 phosphorylates the cytoskeletal proteins myosin, ankyrin, troponin, spectrin, and protein 4.1; neural filaments; neural cellular adhesion molecules; RNA polymerases I and II; translation initiation factors 4B, 4E, and 5; tRNA synthetases; simian virus 40 large T antigen; the insulin receptor; the regulatory subunit (phosphatase inhibitor 2) of protein phosphatase 1; the erythrocyte anion transporter; and metabolic enzymes, including glycogen synthase [9,11]. Some of these substrates undergo defined functional changes when phosphorylated by CKI. The CK1 family not only have numerous substrates but also regulates diverse cellular processes including a plethora of pathways responsible for differentiation [12], proliferation, cell cycle progression [13], DNA replication and damage response [14], chromosome segregation [15], mRNA metabolism [16], cytoskeleton maintenance, membrane trafficking [17], nucleo-cytoplasmic shuttling of transcription factors [18], circadian rhythms [19], Wnt signaling pathways [20], apoptosis [21], translation initiation [22], and cell migration [23,24]. Therefore CK1 deregulation has been linked to neurodegenerative diseases like Alzheimer’s, sleeping disorders and proliferative diseases such as cancer [25].

The CK1 has been found in the nucleus, cytoplasm and membrane fractions of eukaryotic cells [4]. The subcellular localization of the CK1 isoforms is mainly regulated by binding to intracellular structures or protein complexes and thereby plays a role in substrate-recognition and CK1 activity [26,27]. The CK1 isoforms was found to play an important role in cancer progression in different types of tumors [28]. The localization of CKlα in the mitosis was researched by immunofluorescent studies using mouse fibroblasts and CHO cells [9]. In interphase cells, CK1α was localized to vesicular cytosolic structures. When cells enter prophase, the localization of CK1α increases around the centrosome, and there is uniform colocalization of CK1α with the microtubule aster. As cells progress into mitosis, the CK1α becomes localized to mitotic spindle fibers and there is no longer detectable astral microtubule localization. Moreover, in mitosis, CK1α localizes to kinetochore fibers. As cells progress into anaphase, CK1α localization appears restricted to regions of microtubules between the centrosome and the chromosomes. The CK1α localization on microtubules decreases as cells progress to telophase. In telophase, CK1α is localized to the centrosome, but there is no localization to midbody microtubules [29]. Taken together, these results suggest that CK1α relocalizes from vesicular structures to the centrosome and aster microtubules in prophase and with kinetochore microtubules and possibly other interpolar microtubules during mitosis [30]. CK1δ was localized to the centrosomes, co-localized with γ-tubulin and associated with the mitotic spindle in many types of cells [31]. CK1ε is most like CK1δ with greater than 98% identity within the protein kinase domain, and also reported to be localized to the centrosomes in several types of cells [32].

During mouse oocyte meiosis maturation and early embryo development, Ck1α mRNA was all expressed from GV to the late 1-cell stage (GV, GVBD, MI, AI-TI, MII, AII-TII, pronuclear and late 1-cell stage), achieved the highest level in M phase, including MI, MII and metaphase of the 1-cell stage when chromosomes are highly congressed. The CK1α protein expression profile was consistent with the profile of mRNA levels except for GV [33]. The protein expression level of CK1δ and CK1ε were same as CK1α, relatively low at GV stages and then gradually increased at MI and MII stages [34].

The subcellular localization of CK1α in oocyte meiosis had some contradictory results (Figure 1). The first research showed that CK1α localized to the plasma membrane in the mouse GV oocyte and in the spindle area in the MII stage [35]. Subsequent our results showed that CK1α was colocalized with condensed and congressed chromosomes in mouse oocyte meiosis and mitosis of early embryo development, but was not detected in the spindle area. Recently, Qi et al. investigated subcellular localization of endogenous CK1 using immune fluorescent analysis with CK1δ and CK1ε specific antibodies and reported that CK1δ was distributed in both cytoplasm and GV, with slightly more concentrating in the GV, and there were usually one or two point signals adjacent to or around the GV at GV stage. At MI and MII stages, when chromosomes were aligned at the equatorial plates, CK1δ was localized to the two sides of aligned chromosomes. The localization pattern of CK1ε was similar to that of CK1δ. They also detected the localization of exogenous CK1α and found that exogenous CK1α was mainly localized to the spindle poles in mouse oocytes at both MI and MII stages. The different localizations of CK1α observed may be due to the different specificities of the CK1α antibodies that were used, as polyclonal antibodies could give non-specific signals.

Figure 1: Subcellular localization of CK1α in mouse MII oocyte. (A) CK1α was associated with the spindle. The data comes from Gross SD, 1997. (B) CK1α was colocalized with condensed and congressed chromosomes. The data comes from Wang L, 2013. (C) CK1α was concentrated at spindle poles and co-localized with γ-tubulin. The data comes from Qi ST, 2015.

The CK1 isoforms represent central components to regulate the cell cycle progression, spindle-dynamics, and chromosome segregation [5]. CK1α is located at the centrosome, microtubule asters, and the kinetochore in mitosis. Depletion of CK1α using an RNAi based approach in Drosophila cultured cells, resulted in perturbation of interphase nuclear morphology. The results also showed that CK1α functioned to prevent centromere dispersal, inhibited chromosome compaction, and promoted chromosome pairing. Therefore, CK1α is an important modulator of interphase genome organization, regulating homologous chromosome pairing, centromere clustering, and chromosome compaction in Drosophila cultured cells and in vivo [36]. Furthermore, CK1α affected these processes by attenuating interphase condensin II activity as CK1α function was required for protein turnover of the Cap-H2 condensin II subunit. CK1α was a negative regulator of interphase condensin II activity by promoting Cap-H2 destruction and limiting chromatin-bound Cap-H2 levels [37].

In addition, CK1δ especially associates with the spindle apparatus during mitosis and directly modulates MT by phosphorylation of α-, β-, and γ-tubulin, thereby exerting stress-induced functions at the spindle apparatus and the centrosome [38]. Recently, knockdown of CK1δ by siRNA was reported to inhibit microtubule nucleation at the Golgi apparatus [39]. Furthermore, homologs of CK1, such as casein kinase 1-like 6 (CKL6), associate with cortical MT in vivo and phosphorylate tubulin in vitro [40]. CK1δ regulates microtubule- and spindledynamics in response to genotoxic stress in order to maintain genomic stability by site-specific phosphorylation of tubulin.

The nuclear enzyme topoisomerase IIα (TopoIIα) is able to cleave DNA in a reversible manner and can facilitate transcription and replication of chromatin templates in mammalian cells. CK1ε phosphorylates TopoIIα on serine 1106 in G2/M cells, inducing the TopoIIα chromosome localization and decatenation function as well as sensitivity to TopoIIα -targeting drugs. Cdc7 cosilencing or CKIε overexpression in geminin-silenced cells restored TopoIIα chromosomal localization and prevented the formation of chromosome bridges. This finding suggests that CKIε is a positive regulator and Cdc7 is a negative regulator of TopoIIα chromosomal localization and function [41].

Numerous studies have demonstrated that CK1 might regulate cell cycle progression through interaction with the Wnt pathway and p53. CK1α formed a genetic and physical interaction with the murine double minute chromosome 2 (MDM2) oncoprotein resulting in degradation of the p53 tumour suppressor. Pharmacological inhibition of CK1 increases p53 protein level and induces cell death, whilst RNAimediated depletion of CK1α stabilizes p53 and induces growth arrest [25]. Therefore, the coordinated function of both CK1 and p53 could ensure the integrity of the centrosome and thereby maintain genomic stability. CK1δ is associated to the centrosome and related to Wnt3- dependent neurite outgrowth. CK1δ co-localizes with DVL2 at basal bodies and gradually accumulates at centrosomes when cells proceed through the cell cycle [42]. CK1δ and CK1ε are anchored at the centrosome through interaction with AKAP450 [31] and that CK1δ phosphorylates EB1, which is relevant for centrosome positioning during T-cell activation [43]. These further underlined that CK1 had regulatory roles at the centrosome.

In mammalian cells, CK1α was first reported to localize to vesicular cytolic structures and centrosome in interphase cells, and then associated with spindles in mitosis [9]; CK1δ was localized to centrosomes, co-localized with γ-tubulin and was associated with the mitotic spindles under DNA damage; and CK1ε was concentrated at centrosomes [31]. Cell treated with IC261 caused mitotic spindle defects and cell cycle arrest. All these results indicated that CK1 activity may be related to spindle assembly [38].

In S. cerevisiae, deletion of CK1 (HRR25 gene) results in a phenotype in which the yeast cannot enter meiosis or undergo division but are defective in the ability to segregate chromosomes and during mitosis a fraction of cells are defective in nuclear segregation [44]. Two other protein kinases from yeast have been cloned (YCK 1 and 2) that are homologous to the bovine CK1s; deletion of either of these CK1s results in no phenotypic change, but when both are deleted, the cells are not viable [45].

In budding yeast, CK1 δ/ε was a subunit of the monopolin complex required for the mono-orientation of sister kinetochores during meiosis I. The fission yeast CK1 δ/ε isoforms Hhp1 and Hhp2 were required for full levels of Rec8 phosphorylation and for efficient removal of Rec8 at the onset of anaphase I revealing a novel function of this evolutionarily conserved kinase (Figure 2). First, CK1δ/ε isoforms phosphorylate Rec8. Second, a complex of Shugoshin (Sgo) and PP2A is recruited by Bub1 to centromeres to protect centromeric cohesin by dephosphorylating Rec8. Then, segregation of chromosomes during meiosis I was triggered by separase cleavage of phosphorylated Rec8 along chromosome arms, while centromeric cohesin was protected from separase cleavage during meiosis I by the Sgo1/PP2A complex. Centromeric cohesin was only cleaved during meiosis II, hence allowing segregation of sister chromatids. Rec8 phosphorylation promotes its removal at the onset of anaphase raises the possibility that the Sgo1/ PP2A complex protects centromeric cohesin by dephosphorylating Rec8. S. cerevisiae Rec8 with phosphomimetic mutations is no longer protected from separase at centromeres during meiosis I and forced localization of excess CK1δ/ε at the pericentromeric region abrogates the ability of Sgo1/PP2A to protect centromeric Rec8. These results suggested that Sgo1/PP2A protects centromeric cohesin from separase cleavage by opposing CK1-dependent phosphorylation of Rec8. This mechanism may be evolutionarily conserved, because similar observations were made in budding and fission yeast, and both Rec8 and CK1 proteins are present in most eukaryotes.

Figure 2: Model of CK1 in the segregation of chromosomes during meiosis I. First, CK1δ/ε isoforms phosphorylate Rec8. Second, a complex of Shugoshin (Sgo) and PP2A is recruited by Bub1 to centromeres to protect centromeric cohesin by dephosphorylating Rec8. Then, segregation of chromosomes during meiosis I was triggered by separase cleavage of phosphorylated Rec8 along chromosome arms, while centromeric cohesin was protected from separase cleavage during meiosis I by the Sgo1/PP2A complex.

Rec8 phosphorylation by CK1 and Cdc7-Dbf4 kinase regulates cohesin cleavage by separase during meiosis. In addition, previous studies showed that CK1α exists and is activated in mouse oocytes and that it regulates procession of interphase to mitosis during the first mitotic cell cycle in embryos [35].

In 2010, we used proteomics analysis to compare protein difference of mouse oocyte MII stage meiotic spindles between normal and spindles that form after somatic cell nuclear transfer (SCNT). We found that CK1α was significantly decreased in SCNT constructs, accompanied by chromosomes misalignment in SCNT embryos [46]. Then, we investigated function of CK1α during mouse oocyte meiotic maturation and early embryo development. The functions of CK1α on chromosome alignment also were studied by functional depletion, pharmaceutical inhibition and activation approaches. The results showed that both inhibition and activation of CK1α had negative effect on oocyte maturation and early embryo development. Depletion of CK1α with specific-morpholinos caused severe protein expression decreased and consequently observed defects in the interaction of microtubules and centromeres on chromosomes, plate thickness increased and failure of the first polar body extrusion. Blocking of CK1α function with D4476, (4[4-(2,3-dihydro-benzo[1,4]-dioxin- 6-yl)-5-pyridin-2-yl-1-H-imidazol-2-yl]benzamidine) which is an ATP-competitive inhibitor, had the same results with the morpholino injection, such as expression of CK1a was decreased; chromosome congression failed; oocytes arrested at pro-MI phase; PB1 extrusion failed or extruded giant PB1; the ability of embryo development was impaired. However, mouse oocytes treated with pyrvinium pamoate (PP), which increased phosphorylation and allosteric activation of CK1α [47], induced oocyte meiotic maturation failure, severe congression abnormalities and misalignment of chromosomes. These results indicated that CK1α affect homologous chromosome alignment, congression and segregation in the oocyte meiosis and play an important role in early embryo development.

CK1α exhibited analogous functions with surviving,that correlated with the interaction of microtubules and centromeres on chromosomes in the process of oocyte meiotic maturation [48]. Casein kinase 2 (CK2), another casein kinase family member, directly interacted with survivin through β-catenin-Tcf/Lef-mediated transcription in Wnt signaling [49]. Meanwhile, CK1α also participated in the same pathway and allosteric activation of CK1α as an effective mechanism to inhibit Wnt signaling. Wnt signaling increases cytoplasmic levels of β-catenin, which enters the nucleus and interacts with other factors to activate a β-catenin-Tcf/Lef-mediated transcriptional program [47]. But high expression of β-catenin induced abnormal chromosome separation. Therefore we suppose that CK1α might involve in chromosome alignment through the Wnt signaling pathway. Furthermore, two homolog chromosomes were connected with each other at metaphase I, and cohesion together with Rec8 mediated the linkage between sister chromatid arms in the bivalent chromosomes [50]. Rec8 was phosphorylated along chromosomes and Sgo1-PP2A prevents the centromeric Rec8 dephosphorylation in meiosis. Once anaphase I is initiated, phosphorylated Rec8 on the chromosome arms was cleaved by separase, leading to chromosome separation [51]. Blocking CK1α may cut off the phosphorylation of downstream factors and then relevant proteins are unable to integrate with chromosome arms or centromeres. Consequently, chromosome dynamics were affected and anaphase I failed to proceed. However, constitutively activated Ck1α inhibits the function of the Wnt/β-catenin signaling pathway to affect the function of securin, which was a key factor in oocyte meiosis and a target of β-catenin transcriptional activation in colorectal adenomas [52]. CK1α phosphorylated Ser45 of β-catenin is the priming reaction of β-catenin proteasomal degradation [53]. And high expression of β-catenin induced abnormal chromosome separation [52]. Thus, constitutively activated Ck1α might disturb the securin inducing the PB1 extrusion failure and misalignment chromosome.

Our experimental data suggested that CK1α has a pivotal role in regulating chromosome congression and separation during oocyte meiotic maturation and early embryo development [33]. However, a recent study of Qi et al. was inconsistent with our results, which showed that CK1α, CK1δ and CK1ε were not essential for chromosome separation, as loss-of-function of CK1α, CK1δ and CK1ε either individually or simultaneously by RNAi or dominant-negative approach had no effect on homologous chromosome segregation and polar body extrusion. Furthermore, overexpression of exogenous CK1α, CK1δ and CK1ε, both individually and simultaneously, caused little effect on eitherthe meiosis process, spindle organization or chromosome alignment. Their report demonstrate that although CK1α, CK1δ and CK1ε were all localized to MTOCs or spindle poles, they were not the kinase responsible for Rec8 phosphorylation during mouse oocyte meiosis, indicating that CK1 was probably not essential for mouse oocyte meiotic maturation [34]. The contradictory results need further investigation.

Isoforms of CK1 family have been shown to phosphorylate key regulatory molecules involved in cell cycle, transcription and translation, the structure of the cytoskeleton, cell-cell adhesion and receptorcoupled signal transduction. Respecting this involvement in important cellular signal transduction pathways, it is reasonable that dysregulation of CK1 isoforms has been linked to the incidence of inflammatory and proliferative diseases but also to neurodegenerative disorders. In this review we are mostly interested in the cell division. CK1 isoforms play an important role in cell division, both mitosis and meiosis. In mammals, CK1 regulate the transition from interphase to metaphase in mitosis. In budding yeast and fission yeast, CK1 phosphorylate Rec8 subunits of cohesin complex and regulate chromosome segregation in meiosis. However, the functions of CK1 in mammalian oocyte meiosis remain elusive and more researches are still need.
