An Unusual Form of Avellino Dystrophy after Laser in situ keratom
Journal of Clinical and Experimental Ophthalmology

Journal of Clinical and Experimental Ophthalmology
Open Access

ISSN: 2155-9570

+44 1223 790975

Case Report - (2011) Volume 2, Issue 6

An Unusual Form of Avellino Dystrophy after Laser in situ keratomileusis: A Late Onset or Recurrence?

Kyung-Sun Na and Man Soo Kim*
Department of Ophthalmology and Visual Science, Gangnam St. Mary’s Hospital, College of Medicine, The Catholic University of Korea, Seoul, Korea
*Corresponding Author: Man Soo Kim, Department of Ophthalmology and Visual Sciences, Gangnam St. Mary’s Hospital, College of Medicine, The Catholic University of Korea, #505 Ban-Po-Dong Seo-Cho-Gu, 137-040, Seoul, Korea

Abstract

Purpose: To report an unusual manifestation of a corneal deposit of Avellino corneal dystrophy (ACD) after bilateral, simultaneous laser in situ keratomileusis (LASIK).

Methods: A 36-year-old Korean woman who underwent uncomplicated, bilateral LASIK and repeated phototherapeutic keratectomy (PTK) in her left eye due to corneal opacities, showed numerous, fine, white opacities with central corneal stromal haze in the left eye, which was the typical manifestation of the recurrent form of ACD. However, in the right eye, several discrete white opacities were deposited in the central anterial stroma, which was a morphologic feature of the natural course of ACD.

Results: The heterozygous R124H (CGC→CAC) mutation of the BIGH3 gene was found in her genomic DNA extraction.

Conclusion: Further studies should be focused on what is responsible for the differences of the onset period and the shapes of the deposits in patients with ACD.

Keywords: Avellino corneal dystrophy, Laser in situ keratomileusis, Phototherapeutic keratectomy, Ophthalmic imaging, Eye diseases

Introduction

Granular dystrophy type II (Avellino corneal dystrophy, ACD) is an autosomal dominant corneal stromal disease that shares features of both granular and lattice corneal dystrophies. This disorder is caused by a R124 mutation in the TGFB I gene, which is activated by transforming growth factor (TGF)-b [1-4].

Recent studies have shown that laser in situ keratomileusis (LASIK) aggravates corneal deposits in patients with exacerbated ACD and so LASIK shoud be avoided in these patients [5-8]. All of the exacerbated corneal deposit of ACD after LASIK in the literlauture showed multiple, fine, extensive opacities in the anterior stroma, and they were mainly concentrated in the LASIK flap interface with or without diffuse central corneal stromal haze. The manifestations of the recurred, or secondary form of ACD is significantly different from the natural-onset, or primary form for the morphological features.

We report here on an unusual manifestation of a corneal deposit of ACD after bilateral, simultaneous LASIK.

Case Report

A 36-year-old Korean woman reported blurred vision of both eyes for 6 years. She underwent uncomplicated, bilateral LASIK that was performed elsewhere 8 years ago in other clinic. Decreased visual acuity occurred 24 months after LASIK surgery, and two additinal phototherapeutic keratectomy (PTK) procedures were done in her left eyes at the same clinic. Preoperatively, the spherical equivalent manifest refraction was -3.50 diopter in the right eye and -3.00 diopter in the left eye, yielding 20/20 best spectacle-corrected visual acuity (BSCVA) in both eyes. The central corneal thickness was 550μm on the right eye and 535μm on the left eye, and the intraocular pressure was 18mmHg in both eyes. According to retrospective chart review of the clinic, anterior corneal segement examination showed a clear corneal surface with no deposit. Uncomplicated LASIK surgery was performed and the uncorrected visual acuity was remained 20/20.

Twenty four months after the surgery, the patient reported glare and visual discomfort, and especially in the left eye. Her BSCVA was 20/20 in both eyes and the ophthalmologist found a few white granules on the anterior stroma, and this was worse in the left eye. The surgeon performed PTK two times at 2 and 4 years after the previous LASIK in the left eye to remove the corneal deposit. The visual disturbance was improved immediately after the PTK; however, the corneal deposits were exacerbated after a few months. The patient was referred to our clinic for consultation.

On her first visit, the manifest refraction was +1.00 -1.75 x 170 OD and +1.25 -1.00 x 50 OS, yileding 20/20 BSCVA in both eyes. Slitlamp examination showed numerous, fine, white opacities with central corneal stromal haze in the left eye, which was the typical manifestation of the recurrent form of ACD after LASIK. However, in the right eye, several discrete white opacities were deposited in the central anterial stroma, which was a morphologic feature of the natural course of ACD. There was no signs of inflammation, edema or thinning, and no other ocular abnormalities were noted. A pedigree analysis and slit-lamp examination of her parents and siblings showed no family history of corneal dystorphy.

After informed consent was obtained, genomic DNA was extracted from the peripheral leukocytes of the patient and the heterozygous R124H (CGC→CAC) mutation of the BIGH3 gene was found.

clinical-experimental-ophthalmology-anterior-stroma

Figure 1: Slit-lamp photograph of granular deposits of anterior stroma in Avellino corneal dystrophy. The right eye shows discrete stromal opacities with intervening clear stroma and sparing of the periphery.

clinical-experimental-ophthalmology-opacities-sparing

Figure 2: The left eye shows confluent and ground-glass like opacities sparing of the periphery.

Prednisolone acetate 0.12% and ofloxacin 0.3% were used four times daily in both eyes for 2 months without any improvement. The corneal deposits of both eyes showed no progression or improvement on the slit-lamp examination, and the patient’s symptoms were stationary without any changes. The BSCVA remained 20/20 during the 1 year follow-up period and the patient was recommended to undergo further observation.

Discussion

Recurrence of ACD has been observed after excimer laser corneal surgery, including laser epithelial keratomileusis (LASEK) [9], LASIK [5-8] and PTK [10,11]. To treat ACD, PTK, lamellar keratoplasty, deep lamellar kearotplasty, and penetrating keratoplasty (PKP) were used, however, the recurrence remains unsolved [12-14]. In the recurrent or secondary form of ACD, the opacities are diffuse, confluent and fine whitie opacities rather than the larger, discrete white deposits that are the typical manifestation of natural-onset or primary heterozynous ACD in the abscence of corneal surgery. In our patient, the left eye showed a typical recurrent feature, but the right eye showed a typical natural-onset feature. One would raise a question that there is possibilities that the surgeon who examined the patient before LASIK was not aware of the minimal evidences of ACD, which we could not idenify because the prior laser surgeries were operated in other clinic. If we assume that these lesions were the aggravated form of ACD after LASIK, then the left eye still showed an unprecedented characteristic. On the contrary, if we assume that the corneal deposits developed irrespective of the corneal surgery, then the age of onset would be in her early thirties. Considering that the heterozynous ACD usually appears during the first or second decade of life4, our case has a very rare and unusual period of onset.

ACD was originally described in patients with ancestry traced to Northern Italy, and specifically around the region of Avellino [15], but more recently, ACD has been reported in other parts of the world. Until the mid 1990’s, the diagnosis of ACD was obtained mainly from the morphological findings. Due the development of gene analysis, it is widely accepted that the diagnosis of Avellino dystorphy should be genetically confirmed. However, the pathogenesis of ACD is unclear, except for the mutation in codon 124 of the BIGH3 gene (histidine replacing arginine), and this codes for the resultant TGFb- induced cell adhesion protein keratoepithelin (68 Kda), which is reponsible for the disease progression. The mechanism for the worsening of ACD after LASIK remains elusive. TGFb is a well known cytokine associated with BIGH3 protein and any insult to the cornea could be related to an increased TGFb production and the resultant BIGH3 protein deposit. In our patient, a serial PTK induced a more prominent expression of TFGb in the keratocytes in the left eye as compared to that of the right eye, which underwent LASIK only when we assumed that the ACD of both eyes was a recurrent form.

The prevailing theory is that the stimulation of the mutated keratoepithelin protein in ACD corneas by LASIK seems to be independent of TFGb [7]. Generally, the recurrence of ACD after LASIK is more severe than that after PRK or PTK. However, the epithelial basement membrane and Bowman’s layer remained intact after LASIK surgery, and there was a minimal increase in TGFb in the first few months and this became undetectable after only a few months. When we look at our patient from this point of view, we could conclude that the right eye showed the primary form of ACD in the natural course, and only the left eye showed the recurrent form of ACD after PTK. The morphological manifestation of the left eye was similar to the majority of the previously reported cases of recurrence after PTK.

BIGH3 mutation analysis may help to distinguish ACD from granular corneal dystrophy, yet for cases like ours, there is no other tool to differentiate the primary and the secondary forms of ACD. Hence, we should consider every possibility whether it is late onset with a natural course of ACD or it is a laser-induced recurrent form of ACD.

In summary, great care should be taken not to miss even the minimal evidence of ACD before performing LASIK. Although surface ablation procedures such as PTK have been considered effective methods for removing the opacities, the potential for recurrence and exacerbation of these deposits should be considered. Further studies should be focused on what is responsible for the differences of the onset period and the shapes of the deposits in patients with the primary and secondary forms of ACD, even though they share the same mutation on exon 4 (the R124H mutation) in the TGFb gene.

References

  1. Kocak-Altintas AG, Kocak-Midillioglu I, Akarsu AN, Duman S (2001) BIGH3 gene analysis in the differential diagnosis of corneal dystrophies. Cornea 20: 64-68.
  2. Holland EJ, Daya SM, Stone EM, Folberg R, Dobler AA, et al. (1992) Avellino corneal dystrophy. Clinical manifestations and natural history. Ophthalmology 99:1564-1568.
  3. Konishi M, Yamada M, Nakamura Y, Mashima Y (2000) Immunohistology of kerato-epithelin in corneal stromal dystrophies associated with R124 mutations of the BIGH3 gene. Curr Eye Res 21: 891-896.
  4. Folberg R, Alfonso E, Croxatto JO, Driezen NG, Panjwani N, et al. (1988) Clinically atypical granular corneal dystrophy with pathologic features of latticelike amyloid deposits. A study of these families. Ophthalmology 95: 46-51.
  5. Lee ES, Kim EK (2003) Surgical do's and don'ts of corneal dystrophies. Curr Opin Ophthalmol 14:186-191.
  6. Kim TI, Kim T, Kim SW, Kim EK (2008) Comparison of corneal deposits after LASIK and PRK in eyes with granular corneal dystrophy type II. J Refract Surg 24: 392-395.
  7. Awwad ST, Di Pascuale MA, Hogan RN, Forstot SL, McCulley JP, et al. (2008) Avellino corneal dystrophy worsening after laser in situ keratomileusis: further clinicopathologic observations and proposed pathogenesis. Am J Ophthalmol 145: 656-661.
  8. Chiu EK, Lin AY, Folberg R, Saidel M (2007) Avellino dystrophy in a patient after laser-assisted in situ keratomileusis surgery manifesting as granular dystrophy. Arch Ophthalmol 125: 703-705.
  9. Lee JH, Stulting RD, Lee DH, Lee CS, Kim WC, et al. (2008) Exacerbation of granular corneal dystrophy type II (Avellino corneal dystrophy) after LASEK. J Refract Surg 24: 39-45.
  10. Inoue T, Watanabe H, Yamamoto S, Maeda N, Inoue Y, et al. (2002) Recurrence of corneal dystrophy resulting from an R124H Big-h3 mutation after phototherapeutic keratectomy. Cornea 21: 570-573.
  11. Dogru M, Katakami C, Nishida T, Yamanaka A (2001) Alteration of the ocular surface with recurrence of granular/avellino corneal dystrophy after phototherapeutic keratectomy: report of five cases and literature review. Ophthalmology 108: 810-817.
  12. Park KA, Ki CS, Chung ES, Chung TY (2007) Deep anterior lamellar keratoplasty in Korean patients with Avellino dystrophy. Cornea 26: 1132-1135.
  13. Moon JW, Kim SW, Kim TI, Cristol SM, Chung ES, et al. (2007) Homozygous granular corneal dystrophy type II (Avellino corneal dystrophy): natural history and progression after treatment. Cornea 26: 1095-1100.
  14. Nassaralla BA, Garbus J, McDonnell PJ (1996) Phototherapeutic keratectomy for granular and lattice corneal dystrophies at 1.5 to 4 years. J Refract Surg 12: 795-800.
  15. Dolmetsch AM, Stockl FA, Folberg R, Gensini I, Burnier MN Jr (1996) Combined granular-lattice corneal dystrophy (Avellino) in a patient with no known Italian ancestry. Can J Ophthalmol 31: 29-31.
Citation: Na KS, Kim MS (2011) An Unusual Form of Avellino Dystrophy after Laser in situ keratomileusis: A Late Onset or Recurrence? J Clinic Experiment Ophthalmol 2:172.

Copyright: © 2011 Na KS, et al. This is an open-access article distributed under the terms of the Creative Commons Attribution License, which permits unrestricted use, distribution, and reproduction in any medium, provided the original author and source are credited.
