SB: Sleep Bruxism; OSA: Obstructive Sleep Apnea; AOB: Anterior Open Bite; CPAP: Continuous Positive Airway Pressure

Bruxism occurs in over 50% of children aged 3-5 yrs., with significant oral and systemic consequences [1]. In adults, a study that relied on self-reporting found that about 8% of a general sample admitted to sleep bruxism (SB) [2]. More specifically, it is thought that about 25% of patients diagnosed with obstructive sleep apnea (OSA) have SB [3]. Indeed, over 50% of patients with mild OSA and 40% of patients with moderate OSA have concomitant SB [4]. Therefore, it appears that SB is related to OSA.

It is thought that SB is a neural response to stress that is mediated via the jaws [5]. Indeed, resolution of episodes of apnea during sleep is thought to eliminate SB [6]. It has been shown in sleep studies that EEG signals spike 4s before an SB event [5], indicating that SB is a centrally-mediated event, and not simply a local, dental occurrence. In fact, the same study [5] showed tachycardia 10s after the SB event, suggesting that SB is associated with a stressor, possibly oxygen desaturation, during sleep. Interestingly, transient hypertension is also associated with SB, as the blood pressure increases by about 25% after SB events [7], indicating that SB is associated with sympathetic activation. It is also thought that SB is associated with micro-arousals during sleep [5], possibly related to upper airway obstruction.

In addition to the above, rhythmic masticatory muscle activity (RMMA) is thought to be secondary to a sequence of events in relation to micro-arousals [8] and, not surprisingly, nearly 90% of SB events occur during periods of sleep arousal. In an earlier study, RMMA was found to be 3 times higher in patients with SB than in controls. However, not all RMMA episodes are accompanied by tooth grinding, and many patients or family members may not be aware of this para-functional activity [8]. But it is thought that contractions of the masticatory muscles are associated with arousal and/or transient oxygen desaturation in patients with OSA [9]. Therefore, we surmise that SB is a sympathetic-activating event likely in response to hypoxia, and appears to be regulated centrally, not peripherally [10].

This case report describes the clinical management of a young patient with SB and anterior open bite (AOB) 3 yrs. after conventional orthodontic treatment, showing resolution of the former and concomitant improvement of the latter.

Aside from continuous positive airway pressure (CPAP), oral appliance therapy helps to maintain the upper airway during sleep. But, some cases can develop unwanted occlusal changes and possibly temporo-mandibular joint dysfunction following long-term oral appliance use [11].

This case report refers to a 17 yr. old female (Figure 1) who gave informed consent and signed a patient release form. She was initially referred by a Chiropractor to our dental office with a chief complaint of bruxism.

Figure 1: The patient had worn holes through her night-guard, revealing a history sleep bruxism.

The patient admitted to grinding her teeth and had worn holes through her night-guard (Figure 2). Screening revealed a history of orthodontic treatment at age 14 yrs. Currently, the patient exhibited a significant degree of orthodontic relapse, presenting as AOB. She also admitted to snoring while asleep, as well as having neck and shoulder pain. The patient had a social history of being a tennis player.

Figure 2: Representative photomicrograph of histopathological features in pulmonary necropsies.

After the patient completed a psychometric assessment in the form of an Epworth Sleepiness Scale (ESS) questionnaire, physical and 3D cone-beam CT scan (i-CAT Imaging Sciences International, PA) evaluations were undertaken, including 3D analysis (Invivo5 software, Anatomage Inc., San Jose, CA), which revealed the following findings; An ESS total score of 10. Forward head posture (Figure 3) with counterclockwise rotation of the head (Figure 1), indicating cervical subluxation.

Figure 3: Counterclockwise rotation of the head from lateral aspect, revealing forward head posture and mandibular retrognathia.

Anterior open bite with anterior crowding (Figure 4A and 4B), indicating orthodontic relapse.

Figure 4: (A) The anterior open bite is evident with minor anterior crowding in the upper arch, indicating orthodontic relapse. (B) The anterior open bite is evident from the lateral aspect, indicating orthodontic relapse.

Flattened cusps of posterior teeth (Figure 5), indicating sleep bruxism.

Figure 5: Note the flattened cusps of posterior teeth, indicating sleep bruxism.

Uvula not visible with mouth open (Figure 6) with Mallampati class IV, suggesting upper airway obstruction.

Figure 6: The uvula is not visible with mouth open (Mallampati class IV), suggesting upper airway obstruction.

Nasal and upper airway obstruction with an upper airway volume of 7.7 cm³ and a minimum cross-sectional area of 120 mm² (Figure 7).

Figure 7: An upper airway volume of 7.7 cm³ and a minimum cross-sectional area of 120 mm² indicates a degree of upper airway obstruction.

The working and differential diagnoses in this case included; Class I malocclusion with anterior open bite (apertognathia), Maxillary hypoplasia and mandibular retrognathia, Obstructive sleep apnea with hypersomnia, Mandibular dyskinesia, and Cervicalgia.

Therefore, a comprehensive treatment plan was formulated as noted below.

The patient was advised to improve her sleep hygiene, including black-out blinds in the bedroom and going to sleep by 11 pm. She was also instructed on keeping her lips closed as much as possible, particularly while at rest. In addition, nutritional counseling [12,13] was implemented. Next, a biomimetic, upper appliance was prescribed (DNA appliance®, Figure 8).

Figure 8: The biomimetic, upper appliance that was prescribed is shown in situ.

The DNA appliance system is designed to correct maxillo-mandibular underdevelopment in both children and adults [14-19]. The patient was instructed to wear the DNA appliance during the late afternoon, early evening and at nighttime during sleep (for approx. 10-12 hrs. in total), but not during the day time and not while eating, partly in line with the circadian rhythm of tooth eruption [20], although this only occurs in children. In addition, a facemask was utilized to protract the maxilla [21]. The patient reported for review and the biomimetic appliance was adjusted every 4 weeks, approximately. At each monthly follow-up, examination for the progress of midfacial development was recorded. Adjustments to the device were performed to optimize its efficacy. Only gentle pressures were transmitted to the teeth, and the functionality of the device was checked with the subject activating a mild force on biting. The patient was encouraged to maintain the sleep, postural and nutritional protocols outlined at the start of treatment.

After 15 months of active treatment, the ESS total score decreased from 10 to 4, the upper airway volume increased from 7.7 cm³ to 24.1 cm³ and the minimum cross-sectional area increased from 120 mm² to 276.5 mm² (Figures 7 and 9).

Figure 9: After 15 months of active treatment, the upper airway volume increased to 24.1 cm³ (from 7.7 cm³) and the minimum cross-sectional area increased to 276.5 mm² from 120 mm² (as shown in Figure 7 above).

Thus, the upper airway volume increased by 313% and the minimum upper airway cross-sectional area increased by 230%. Moreover, the patient reported that she was no longer grinding her teeth and was no longer snoring at night. In addition, she noticed an improved facial appearance and smile esthetics (Figure 10A and 10B).

Figure 10: (A) Significant improvement of the anterior open bite, which lays the foundation for final occlusal interdigitation and anterior coupling, using conventional orthodontic techniques. (B) Significant improvement of the anterior open bite from the lateral aspect is evident.

Furthermore, the patient reported that she woke up feeling refreshed and her athletic performance during tennis matches appeared to have improved also.

Currently, it is thought that preventive therapy cannot effectively cure sleep bruxism but various treatment protocols for its management are available [22]. This particular case report represents a patient who followed all treatment recommendations conscientiously, and her progress and results appear to reflect her pursuit of health. However, a major limitation of this case report is the lack of a PSG study to document bruxism and OSA at both the baseline and post-treatment phases. However, psychometric measures, such as an Epworth Sleepiness Scale questionnaire were used to confirm the presence of bruxism, its severity and daytime sleepiness. In addition, the patient admitted to grinding her teeth, had worn holes through her night-guard (Figure 2), and the flattened cusps of her posterior teeth (Figure 5) were indicative of sleep bruxism. As a result of biomimetic oral appliance therapy, her upper airway was developed (Figures 7 and 9) so that mouth breathing was corrected and she could revert back to nasal breathing. This change in function appears to have resolved her chief concern of sleep bruxism. In fact, a comparable finding was reported in children that underwent a similar procedure for bruxism [23]. But, in addition, the nasal mode of breathing allowed her lips to contact gently while at rest. This oral posture permitted the tongue to sit in the palate, which is a prerequisite for the resolution of AOB, as noted in this particular case (Figure 10A and 10B).

Currently, the patient is being monitored for long term follow up, and is continuing with atlas-orthogonal chiropractic care as needed. Specifically, an overnight sleep study will be undertaken to assess the patient’s sleep architecture and identify any signs of OSA. Indeed, a multi-disciplinary approach will be adopted. For example, it has been shown that both craniofacial [24] and systemic [25] improvements can be achieved using a combination of chiropractic adjustment and biomimetic oral appliance therapy. In addition, oral myofunctional therapy can correct tongue posture and behavior [26,27]. Furthermore, development of the lower arch may be required, using a lower appliance to permit arch re-coordination prior to final occlusal detailing with a finishing phase of orthodontics.

Micro-arousals during sleep are considered to be one of the main factors initiating nocturnal jaw-closing muscles activation or bruxism, which may be related to neurotransmitter and basal ganglia disorders [28]. Therefore, further studies are needed to clarify the pathophysiology of SB and develop new protocols to target therapy for patients with concomitant SB and OSA. A multi-disciplinary approach may be appropriate for patients that present to a dental office with issues relating to SB. The protocol described in this article may also be applicable to cases of posterior open bite associated with mandibular advancement appliance therapy for the management of OSA. That premise remains as the basis for future studies.

This work was support by a grant to Dr Felix Liao by The PACE Institute, Oregon, USA, a non-profit entity.
