Review Article - (2018) Volume 10, Issue 2

How to use Green Technology to Enhance Antioxidant Efficiency of Plant Extracts: A Novel Strategy

Wael Mahmoud Aboulthana1* and Hager Hussein Sayed2
1Biochemistry Department, Genetic Engineering and Biotechnology Division, National Research Centre, Dokki, Giza, Egypt
2Chemistry and Zoology Department, Faculty of Science, Fayoum University, Fayoum, Egypt
*Corresponding Author: Wael Mahmoud Aboulthana, Biochemistry Department, Genetic Engineering and Biotechnology Division, National Research Centre, 33 Bohouth St., P.O. 12622, Dokki, Giza, Egypt, Tel: +201124582973/ +201014343303 Email:

Abstract

Nanotechnology is a rapidly growing science of producing and utilizing the nano-sized particles. It was necessary to develop another non-toxic and environmentally friendly procedure for production of nanoparticles by mean of green technology to avoid production of the hazardous chemicals (sodium borohydride, sodium citrate, ascorbate, elemental hydrogen, Tollen’s reagent, N,N-dimethyl formamide and poly (ethylene glycol) block copolymers) produced during the chemical preparation. The metal nanoparticles (MNPs) (silver, gold, platinum, copper and zinc oxide) were biosynthesized through the reaction with plant extract by bio-reduction mechanism. Among all noble MNPs, the silver nanoparticles (AgNPs) are non-toxic and gained boundless interests due to their characteristic properties in addition to their significant antibacterial, antifungal and anti-inflammatory effects.
The UV-Vis Spectrophotometer, X-Ray Diffractometer (XRD), Atomic Force Microscopy (AFM), Fourier Transform Infrared (FT-IR) Spectroscopy, Dynamic Light Scattering (DLS), Energy Dispersive X-ray Spectroscopy (EDX), Scanning Electron Microscope (SEM), Field Emission Scanning Electron Microscope (FESEM) and Transmission Electron Microscope (TEM) are considered as the most widely used techniques for characterization of the synthesized nanoparticles.
Incorporation of the AgNPs into the plant extracts enhanced the antioxidant properties due to increasing the total polyphenolic compounds which exhibit more antioxidant potentials and possesses significant cytotoxicity and free radical scavenging activity than the crude ones. It was revealed that deposition of the nanoparticles was greatest in liver followed by blood, spleen, kidney, lungs, brain, reproductive organs, thymus and heart. Removal of the nanoparticles from the body through renal clearance is considered as a multifaceted process. The review concluded that it is necessary for undergoing further studies to evaluate the deleterious effects that may be occurred as a result of administration of the nanoparticulated extracts.

Keywords: Nanotechnology; Green technology; Metal nanoparticles; Silver nanoparticles; Renal clearance

Introduction

Nanotechnology is defined as a rapidly growing science of producing and utilizing particles at the nano-scale. It is well known that the nano-sized particles exhibit physicochemical and biological properties differ in fundamental and valuable ways from those of individual atoms and molecules [1,2]. Incorporation of metal nanoparticles (MNPs) into polymeric matrices is considered to be one of the most promising solutions to their inherent stability problem. It showed valuable properties in many practical applications [3].

Nanomedicine is defined as utilization of submicron size (<1 um) modules for treatment and diagnosis of various chronic diseases. Synthesis of nanoparticles eco-friendly is considered as building blocks of the forthcoming generations for monitoring and control of biological system [4]. During preparation of nanoparticles, different organic and inorganic reducing agents, such as sodium borohydride, sodium citrate, ascorbate, elemental hydrogen, Tollen’s reagent, N,N-dimethyl formamide and poly (ethylene glycol) block copolymers are used for reduction of metal ions in aqueous and non-aqueous solutions [5,6]. These chemicals are toxic and led to non-ecofriendly by-products. This may be the reason which leads to the biosyntheses of nanoparticles via green route that does not employ toxic chemicals [7].

Due to formation of these hazardous chemicals during the chemical preparation of nanoparticles, it was necessary to develop other highyield, low cost, non-toxic and environmentally friendly procedures [8,9]. Generally, there are two approaches involved in synthesis of silver nanoparticles (AgNPs), either from "top to bottom" approach or a "bottom to up" approach (Figure 1) [7].

applied-pharmacy-silver-nanoparticles

Figure 1: Different approaches for synthesis of silver nanoparticles.

Bera TK et al. stated that butylated hydroxyl toluene, tertiary butylated hydroquinone and gallic acid esters are the most common synthetic antioxidants that have been restricted and suspected to cause or prompt negative health effects and may lead to cancerous diseases. Consequently, the recent studies have been directed to search in the medicinal plants to select the most suitable one to be utilized for biosynthesis of AgNPs from a silver nitrate (AgNO3) solution by mean of green technology. Then, the nano-extract used for therapeutic purposes as it does not involve any harmful chemicals. In addition, various natural materials like plants, bacteria, fungi, yeast are used for AgNPs synthesis [10-12].

Plant crude extract is rich in the secondary metabolites (phenolic acid, flavonoids, alkaloids and terpenoids) which are mainly responsible for the reduction of ionic into bulk metallic nanoparticles formation. Moreover, these metabolites are constantly involved in the redox reaction to synthesize nano-sized particles [13]. The plant extracts act as reducing and capping agents for synthesis of nanoparticles [14]. They are able to be scaled up for large-scale nanoparticle synthesis [15]. Synthesis of the plant-mediated nanoparticles is preferred because it is cost-effective, environmentally friendly, a single-step method for biosynthesis process and safe for human therapeutic use. Different plant extracts have been studied to be used for synthesis of MNPs in different sizes and shapes [16,2]. Nanocomposites are a combination of two or more organic or inorganic components in which one or more phases with nanoscale dimensions are embedded in a metal, ceramic or polymer matrix. They exhibit a significant proportion of the properties of both constituents such that a better combination of properties is realized. In addition, the constituent phases must be chemically dissimilar and separated by a distinct interface.

Synthesis of AgNPs was extensively studied employing chemical and physical methods, but development of the reliable technology to produce nanoparticles is an important aspect of nanotechnology [1]. It was reported that the AgNPs are of particular interest due to their peculiar properties and wide applications. They are used as antiinflammatory to treat infections in open wounds and chronic ulcers in addition to its effective role in treatment of brucellosis [17,18].

The biological effectiveness of the AgNPs attributed to its ability to increase the proportionately associated with increasing the specific surface area as a result of increasing their surface energy and catalytic reactivity. Various methods have been used for synthesis of AgNPs, like chemical and photochemical reduction, electrochemical techniques and radiolysis methods [19].

The AgNPs were synthesized by reduction of aqueous AgNO3 into AgNPs during the exposure to plant extracts and could be easily monitored by using UV-visible spectrophotometer. Incorporation of AgNPs into the plant extracts enhanced the antioxidant activity at lower concentrations [20]. It was demonstrated that the biosynthesized nanoparticles effectively controlled oxidative stress, genotoxicity and apoptosis related changes and this might be attributed to the increased total phenolic compounds and total flavonides [21]. Polyphenols are the most biologically active classes of secondary plant metabolites that are structurally characterized by presence of one or more phenol units. They play an effective role in preventing chronic diseases owing to their antioxidants potentials [22,23]. Furthermore, [24] reported that incorporation of AgNPs increased concentration of the polyphenolic compounds with respect to the native extract (without AgNPs).

It is worth to mention that MNPs (silver, gold, platinum, copper and zinc oxide) were biosynthesized through the reaction with plant extract by bio-reduction mechanism. Among all noble MNPs, the AgNPs gained boundless interests due to their characteristic properties in addition to their significant antibacterial, antiviral, antifungal and antiinflammatory effects. It is well known that silver is a nontoxic inorganic agent. It is to kill about 650 types of diseases caused microorganisms. It exhibits vital functions as an antiseptic and displays a broad biocidal effect against various microorganisms through disruption of their unicellular membrane thus disturbing their enzymatic activities [25]. Furthermore, synthesis of AgNPs using plant extracts revealed that the nanoparticulated extracts were economic and cost effective. In addition, this technique provide healthier work places, communities, protecting human health and environment, leading to less waste and more safe products [26,27]. As illustrated in Figure 2, silver nitrate (AgNO3) reacts biochemically with plant extract leading to formation of AgNPs through the reaction suggested by [28]. The reaction time is considered as very effective factor affecting the prepared AgNPs. As revealed in Figure 3, color of the reaction mixture changed within 10 min. during green synthesis of AgNPs [29].

applied-pharmacy-biological-synthesis

Figure 2: The proposed mechanism of biological synthesis of nanoparticles.

applied-pharmacy-Color-change

Figure 3: Color change in the reaction mixture within 10 min.

The UV-Vis Spectrophotometer, X-Ray Diffractometer (XRD), Atomic Force Microscopy (AFM), Fourier Transform Infrared (FT-IR) Spectroscopy, Dynamic Light Scattering (DLS), Energy Dispersive X-ray Spectroscopy (EDX), Scanning Electron Microscope (SEM), Field Emission Scanning Electron Microscope (FESEM) and Transmission Electron Microscope (TEM) are considered as the most suitable techniques used widely for characterization of the synthesized nanoparticles.

The XRD as well as TEM considered the most significant technique to examine structural properties of the fabricated nanomaterials. As suggested by [26], it was found that formation and stability of the reduced AgNPs were monitored in the colloidal solution by UV-Vis spectrophotometer analysis. Mean of AgNPs diameter was calculated from the XRD pattern according to line width of the plane, and the refraction peak, using Scherrer’s equation. AFM showed the irregular shapes of AgNPs. The FTIR spectroscopy confirmed the presence of protein as the stabilizing agent surrounding the AgNPs. Moreover, it affirmed the role of plant extract as a reducing and capping agent of silver ions.

Ibrahim reported that the X-ray diffraction revealed the crystalline nature of AgNPs. The SEM and FESEM showed the spherical shaped and monodispersed nanoparticles. TEM confirmed the spherical nature and the crystallinity of nanoparticles. The average size of nanoparticles was 23.7 nm as determined by DLS. The EDX analysis showed the peak in silver region confirming presence of elemental silver. Furthermore, antimicrobial activity of the silver bio-nanoparticles was performed by a well diffusion method [30].

The recent studies documented that silver plant nano-extracts showed possible applications through enhancing the antioxidant properties after incorporation of AgNPs into the plant extract. This was attributed to increasing the active phytoconstituents which exhibit more antioxidant potentials and possesses significant free radical scavenging activity than the crude extracts. This was supported through increasing number of peaks that represent the phenolic compounds in the nanoparticulated extracts. Thereafter, the nanoparticulated extracts found with increased cytotoxicity against growth of human cancer cells compared to the crude ones. In addition, enhancement of total polyphenolic compounds found to be related to the total antioxidant capacity, iron reducing power and free radicals scavenging activity and hence increasing the anticancer activity through lowering growth of the cancer cells [24]. For these reasons, the AgNPs were incorporated into different extracts prepared recently from Moringa oleifera leaves, Bauhinia variegate leaves and Croton tiglium seeds to be utilized for treatment of chronic diseases like cancers and diabetes.

Although it was revealed that deposition of the nanoparticles was greatest in liver followed by blood, spleen, kidney, lungs, brain, reproductive organs, thymus and heart; whereas the 50, 100 and 250 nm particles were deposited in liver followed by spleen and blood [31], the practical studies emphasized that oral administration of the silver nanoparticulated extracts caused no obvious toxicity in the experimental animals [32]. Kidneys are capable of rapidly removing molecules from the vascular compartment. The renal excretion represents a desirable pathway for removal of nanoparticles with minimal catabolism from the body to avoid the possible side effects. Removal of the nanoparticles from the body through the renal clearance that is considered as a multifaceted process involving glomerular filtration, tubular secretion, and finally elimination of the molecule through urinary excretion [33]. Notably, the previous studies did not evaluate the direct clearance and did not measure urine particle losses, so kidney particle levels reflect nanoparticles present in the kidney at the time of harvesting rather than levels that may have been cleared by the kidneys. However, the predominance of accumulation of nanoparticles in liver suggested that the hepatobiliary system was the primary site for agent clearance for nanoparticles from 10-250 nm [32]. Therefore, it is necessary for undergoing further studies to evaluate the deleterious effects that may be occurred as a result of administration of nanoparticles alone or as nanoparticulated extracts.

References

  1. Natarajan K, Selvaraj S, Ramachandra MV (2010) Microbial production of silver nanoparticles. Dig J Nanomater Biostruct 5: 135-140.
  2. Gopinath V, MubarakAli D, Priyadarshini S, Priyadharsshini NM, Thajuddin N, et al. (2012) Biosynthesis of silver nanoparticles from Tribulus terrestris and its antimicrobial activity: a novel biological approach. Colloids Surf B Biointerfaces 96: 69-74.
  3. Rozenberg BA, Tenne R (2008) Polymer-assisted fabrication of nanoparticles and nanocomposites. Prog Polym Sci 33: 40-112.
  4. Cruz D, Fale PL, Mourato A, Vaz PD, Serralheiro ML, et al. (2010) Preparation and physicochemical characterization of Ag nanoparticles biosynthesized by Lippia citriodora (Lemon Verbena). Colloid Surf B 81: 67-73.
  5. Tran QH, Nguyen VQ, Le AT (2013) Silver nanoparticles: synthesis, properties, toxicology, applications and perspectives. Adv Nat Sci Nanosci Nanotechnol 4: 033001
  6. Iravani S, Korbekandi H, Mirmohammadi SV, Zolfaghari B (2014). Synthesis of silver nanoparticles: chemical, physical and biological methods. Res Pharm Sci 9: 385-406.
  7. Ahmed S, Ahmad M, Swami BL, Ikram S (2016) A review on plants extract mediated synthesis of silver nanoparticles for antimicrobial applications: A green expertise. Int J Adv Res 7: 17-28.
  8. Sathyavathi R, Krishna MB, Rao SV, Saritha R, Rao DN, et al. (2010) Biosynthesis of silver nanoparticles using Coriandrum sativum leaf extract and their application in nonlinear optics. Adv Sci Lett 3: 138-143.
  9. Venkatesham M, Ayodhya D, Madhusudhan A, Veera Babu NV, Veerabhadram G, et al. (2012) A novel green one-step synthesis of silver nanoparticles using chitosan: catalytic activity and antimicrobial studies. Appl Nanosci 4: 113-119.
  10. Bera TK, Chatterjee K, Jana K, Ali KM, De D, et al. (2012) Antihepatotoxic effect of "Livshis," a polyherbal formulation against carbon tetrachloride-induced hepatotoxicity in male albino rat. J Nat Pharmaceut 3: 17-24.
  11. Kotakadi VS, Gaddam SA, Rao YS, Prasad TNVKV, Reddy AV, et al. (2014) Biofabrication of silver nanoparticles using Andrographis paniculata. Eur J Med Chem 73: 135-140.
  12. Vidhu VK, Philip D (2014) Spectroscopic, microscopic and catalytic properties of silver nanoparticles synthesized using Saraca indica flower. Spectrochim Acta A Mol Biomol Spectrosc 117: 102-108.
  13. Aromal SA, Philip D (2012) Green synthesis of gold nanoparticles using Trigonella foenum-graecum and its size dependent catalytic activity. Spectrochim Acta A 97: 1-5.
  14. Lakshmanan G, Sathiyaseelan A, Kalaichelvan PT, Murugesan K (2018) Plant-mediated synthesis of silver nanoparticles using fruit extract of Cleome viscosa L.: Assessment of their antibacterial and anticancer activity. Karbala Inter J Modern Sci 4: 61-68.
  15. Saxena A, Tripathi RM, Zafar F, Singh P (2012) Green synthesis of silver nanoparticles using aqueous solution of Ficus benghalensis leaf extract and characterization of their antibacterial activity. Mater Lett 67: 91-94.
  16. Mubarak Ali D, Thajuddin N, Jeganathan K, Gunasekaran M (2011) Plant extract mediated synthesis of silver and gold nanoparticles and its antibacterial activity against clinically isolated pathogens. Colloids Surf B Biointerfaces 85: 360-365.
  17. Alizadeh H, Salouti M, Shapouri R (2013) Intramacrophage antimicrobial effect of silver nanoparticles against Brucella melitensis 16M. Sci Iranica F 20: 1035-1038.
  18. Rawani A, Ghosh A, Chandra G (2013) Mosquito larvicidal and antimicrobial activity of synthesized nano-crystalline silver particles using leaves and green berry extract of Solanum nigrum L. (Solanaceae: Solanales) Acta Trop 128: 613-622.
  19. Khaydarov RA, Khaydarov RR, Gapurova O, Estrin Y, Scheper T, et al. (2009) Electrochemical method for the synthesis of silver nanoparticles. J Nanopart Res 11: 1193-1200.
  20. Johnsona AS, Obota IB, Ukponga US (2014) Green synthesis of silver nanoparticles using Artemisia annua and Sida acuta leaves extract and their antimicrobial, antioxidant and corrosion inhibition potentials. J Mater Environ Sci 5: 899-906.
  21. Abdel Aziz MS, Shaheen MS, El Nekeety AA, Abdel Wahhab MA (2014) Antioxidant and antibacterial activity of silver nanoparticles biosynthesized using Chenopodium murale leaf extract. J SAUDI CHEM SOC 18: 356-363.
  22. Queralt A, Regueiro J, Alvarenga JF, Huelamo M, Leal L, et al. (2015) Characterization of the phenolic and antioxidant profiles of selected culinary herbs and spices: caraway, turmeric, dill, marjoram and nutmeg. Food Sci &Tech 35: 189-195.
  23. Silberstein T, Vardi I, Harlev A, Friger M, Hamou B, et al. (2016) Antioxidants and Polyphenols: Concentrations and Relation to Male Infertility and Treatment Success. Oxid Med Cell Longev 2016: 1-5
  24. Abdelhady NM, Badr KA (2016) Comparative study of phenolic content, antioxidant potentials and cytotoxic activity of the crude and green synthesized silver nanoparticles′ extracts of two Phlomis species growing in Egypt. J Pharmacogn Phytochem 5: 377-383.
  25. Popescu M, Velea A, Lorinczi A (2010) Biogenic production of nanoparticles. Dig J Nanomat Bios 5: 1035-1040.
  26. Logeswari P, Silambarasan S, Abraham J (2013) Ecofriendly synthesis of silver nanoparticles from commercially available plant powders and their antibacterial properties. Scientia Iranica F 20: 1049-1054.
  27. Allafchian AR, Zare MSZ, Jalali SAH, Hashemi SS, Vahabi MR, et al. (2016) Green synthesis of silver nanoparticles using Phlomis leaf extract and investigation of their antibacterial activity. J Nanostruct Chem 6: 129-135.
  28. Tripathy A, Raichur AM, Chandrasekaran N, Prathna TC, Mukherjee A (2009) Process variables in biomimetic synthesis of silver nanoparticles by aqueous extract of Azadirachta indica (Neem) leaves. J Nanopart Res 12: 237-246.
  29. Padalia H, Moteriya P, Chanda S (2015) Green synthesis of silver nanoparticles from marigold flower and its synergistic antimicrobial potential. Arab J Chem 8: 732-741.
  30. Ibrahim HMM (2015) Green synthesis and characterization of silver nanoparticles using banana peel extract and their antimicrobial activity against representative microorganisms. J Radiat Res Appl Sci 8: 265-275.
  31. De Jong WH, Hagens WI, Krystek P, Burger MC, Sips AJ, et al. (2008) Particle size-dependent organ distribution of gold nanoparticles after intravenous administration. Biomaterials 29: 1912-1919.
  32. Mohanpuria P, Rana NK, Yadav SK (2007) Biosynthesis of nanoparticles: technological concepts and future applications. J Nanoparticle Res 10: 507-517.
  33. Longmire M, Choyke PL, Kobayashi H (2008) Clearance Properties of Nano-sized Particles and Molecules as Imaging Agents: Considerations and Caveats. Nanomedicine 3: 703-717.
